Parker 快速接头和附件
Parker Quick Couplings and Accessories
Parker Quick Couplings快速接头
OEM Aftermarket Rigid Mount Connect Under Pressure Coupler (Kubota Replacement) Accepts ISO 5675 Pioneer Tips - 0312-001
0312-001，OEM售后市场用刚性安装阴接头，能在压力下连接，可与符合ISO 5675 Pioneer标准阳接头连接

Pioneer系列刚性安装阴接头可直接安装在阀块或者钢管上，从而消除了对软管总成或者拉断式管夹的需求。 Pioneer's rigid mount couplers are designed to eliminate the need for hose assemblies and break-away clamps by mounting directly to a valve or rigid tubing

0312-001 系列阴接头，承压（液压）可达3000 psi，能与Pioneer 8010系列阳接头或者其他符合ISO 5675标准的阳接头配合连接。 0312-001 Coupler (hydraulic) 3000 psi connects with 8010 Series Pioneer male tips or other ISO 5675 compliant nipples.

0312-001刚性安装阴接头的设计是用于久保田拖拉机OEM用快换的备件。 Pioneer设计允许阴接头与阳接头在压力下进行连接。该系列阴接头能够直接安装在阀块或者钢管上，从而减少了软管总成或者拉断型管夹的连接需求。 The 0312-001 rigid mount coupler was developed as an aftermarket replacement for Kubota tractor OEM couplers. Pioneer's unique design permits connection while both the coupler and male tip are under pressure. These couplers can be mounted directly to a valve or rigid tubing, eliminating the need for hose assemblies and break-away clamps.

Pioneer 0312-001包含5个接头。该系列阴接头与久保田型号3A111-82011是同一个产品。 The Pioneer 0312-001 is available in packages of five. This coupler is the same product as Kubota part number 3A111-82011.

OEM Aftermarket Rigid Mount Connect Under Pressure Coupler (Kubota Replacement) Accepts ISO 5675 Pioneer Tips - 0312-001

技术特点Technical Characteristics:
- Body Size: 1/2""
- Port End: 7/8-14 UNF-2B
- 本体尺寸：1/2英寸
- 尾端连接：7/8-14 UNF-2B

市场Markets:
- 农业Agriculture

特点/优势Features/Benefits:
- Rigid mounting directly to a valve or tubing eliminates the need for hose assemblies and breakaway clamps
- Easy push to connect /pull to disconnect under system pressure
- Enclosed outer housing prevents build up of dust and dirt
- Globally connects with Pioneer universal male tips (nipples) complying to ISO 5675 (not included in Kit)
- Each pack contains five couplings
- Pioneer part number 0312-001 is the same as Kubota part number 3A111-82011
- 能够刚性安装在阀块或者钢管上，从而减少了软管总成或者拉断型管夹的连接需求
- 简单的推动连接/拉开断开方式，能够在系统压力下进行连接
- 封闭的外壳减少灰尘和污垢的积聚
- 可与符合ISO 5675 标准的Pioneer系列通用阳接头（不包含在套件包内）进行配合连接
- 每个包装内包含5个快换接头
- Pioneer型号 0312-001 与久保田型号3A111-82011是同一个产品

应用Applications:
- Kubota Tractors with original coupling interface
- 久保田拖拉机原装快换

Technical Specifications

OEM Aftermarket Rigid Mount Connect Under Pressure Coupler (Kubota Replacement) Accepts ISO 5675 Pioneer Tips - 0312-001 型号
