Parker 针阀
Parker Needle Valves
Needle Valve, High Pressure - 150V Series 150,000 PSI

Parker Autoclave的150V系列针型阀为非旋转式立杆设计，通过5/16英寸的末端连接，工作压力高达150,000 psi（10350 bar）。 这些阀是高强度15-5PH不锈钢的圆柱体。 Parker Autoclave's 150V Series needle valves are a non-rotating rising stem design, with working pressures to 150,000 psi ( 10350 bar) with 5/16” ” end connections. These valves are a cylindrical body of high strength 15-5PH Stainless Steel.

Parker Autoclave的150V系列针型阀是高强度15-5PH不锈钢的圆柱体设计，并具有不旋转的上升阀杆设计，该阀芯采用可更换的镍马氏体时效钢阀座。这些专用阀可在高达150,000 psi（10350 bar）的压力下运行。管道尺寸仅适用于5/16英寸。油管连接采用Parker高压釜的锥和螺纹设计。Parker Autoclave's 150V Series needle valves are cylindrical body design of high strength 15-5PH stainless steel with a non-rotating rising stem design that utilizes a replaceable seat of nickel maraging steel. These specialty valves operate in pressures up to 150,000 psi (10350 bar). The tubing size is only available in 5/16”. Tubing connections utilize the Parker Autoclave cone and thread design.

这些阀门具有许多功能，可在各种应用中提供可靠且无故障的服务。Along with their many features these valves provide dependable and trouble free service in wide variety of applications.

派克 Autoclave 的高压系列针型阀中小孔仪表阀的压力能达到 150,000 PSI，在石油和天然气加工工业上广泛应用.

派克 Autoclave 压力系列针阀压力可达 150,000 PSI，适用于石油和天然气加工行业的小口径仪表应用。

市场Markets:

- Oil and Gas
- Research
-石油和天然气
-研究

特点/优势Features/Benefits:

- Tubing size 5/16”.
- Non-rotating stem prevents stem/seat galling.
- Rising stem/barstock body design.
- Metal-to-metal seating achieves bubble-tight shut-off, longer stem/seat life in abrasive flow, greater durability for repeated on/off cycles and excellent corrosion resistance.
- Cylindrical body of high strength 15-5PH stainless steel with stainless steel packing gland. Tool steel nonrotating stem with replaceable seat of nickel maraging steel. Stem must be actuated with torque wrench (refer to Tools, Installation, Operation and Maintenance section).
- Wedge-type PTFE and leather packing below stem threads with beryllium-copper Autoclave Anti-Extrusion Back up Rings.
- Vee stem tip only
-油管尺寸为5/16”。
-不可旋转的阀杆可防止阀杆/阀座磨损。
-阀杆/棒状阀体的上升设计。
-金属对金属阀座实现了气密性关闭，在磨料流中具有更长的阀杆/阀座寿命，在反复的开/关循环中具有更高的耐用性，并具有出色的耐腐蚀性。
-高强度15-5PH不锈钢的圆柱体，带有不锈钢填料函。工具钢非旋转阀杆，带可更换镍马氏体钢阀座。阀杆必须用扭矩扳手驱动（请参阅“工具，安装，操作和维护”部分）。
-阀杆螺纹下方的楔形PTFE和皮革填充物，带有铍铜高压釜防挤压支撑环。
-仅Vee阀杆尖

应用Applications:

- High Pressure Panels
- High Pressure Fluid Handling Systems
-高压面板
-高压流体处理系统

Technical Specifications

Needle Valve, High Pressure - 150V Series 150,000 PSI 型号

150V5072
