Parker Quick Couplings快速接头
Rigid Mount, Connect Under Pressure, 1/2” Pioneer Agricultural Quick Couplings, ISO 5675, 3000 psi, - 8450 Series Couplers
Pioneer 8450 系列快换阴接头

Pioneer刚性连接快换阴接头，可在压力下进行连接，适合于多种农机液压系统，可满足流体管路需要快速简单地连接的场合，且阴接头或阳接头可任意一端或全部在压力下连接。 Pioneer rigid mount, connect under pressure quick couplers are used across a spectrum of agricultural hydraulic applications where fluid lines require fast and easy connection while either or both the coupler and nipple are under pressure.

8450系列快换阴接头，是Pioneer品牌下的农机快换接头，该系列接头承压（液压）可达3000 psi，并且能在压力下与8010系列快换阳接头（符合ISO 5675 农机通用阳接头）进行连接，阴接头或者阳接头任意一端或者两端同时都可在系统压力下进行连接。 Pioneer 8450 Series agricultural Couplers (hydraulic) 3000 psi, will connect under pressure with 8010 Series Nipples (ISO 5675 Pioneer universal male tips) while either or both the coupler and nipple are under system pressure.

8450 系列快插式快换接头使用锥阀以及推拉式套筒设计，当在刚性连接或者使用5006-4卡箍固定时，可以当做拉断阀使用。阴接头尾端连接时 7/8 - 14 ORB内螺纹或者外螺纹，可以允许直接安装在控制阀或者钢管上。 8450 Series push to connect couplings have poppet valves and a push-pull sleeve design to act as a breakaway when rigidly mounted or held in a 5006-4 clamp. Coupler port ends are 7/8 - 14 ORB threads, male or female, to allow direct mounting to a control valve or rigid tubing.

Rigid Mount, Connect Under Pressure, 1/2” Pioneer Agricultural Quick Couplings, ISO 5675, 3000 psi, - 8450 Series Couplers

技术参数Technical Characteristics:
- Size: 1/2"
- Materials: Steel
- Port Ends: Male ORB, Female ORB
- Seal Options: Nitrile
- 本体尺寸：1/2"
- 材料：碳钢
- 尾端连接形式，ORB外螺纹，ORB内螺纹
- 可选密封：丁腈橡胶

市场Markets:
- 农机设备Agriculture

特点/优势Features/Benefits:
- Globally connects with Pioneer male tips (8010 Series) or any other nipples conforming to ISO 5675
- Straight thread ORB fitting allows direct mounting to a control valve or rigid tubing
- Connect under system pressure on the coupler side and/or on the nipple side
- One handed push to connect operation when the coupler is clamp or rigid mounted
- Outer housing keeps dust and dirt away from the sleeve mechanism
- Compatible with 5006-4 breakaway clamp
- 可与Pioneer品牌下的阳接头（8010系列）或者符合ISO 5675 标准的阳接头进行全球性互换
- ORB直螺纹接头可直接安装在控制阀或者与钢管进行连接
- 可在阴接头或者阳接头一边或者两边同时有压力的情况下进行带压连接
- 当快换阴接头固定连接或者使用管夹固定时，可单手推动式连接操作
- 外部壳体可阻止灰尘或者污物进入套筒
- 可与 5006-4 系列拉断卡箍进行连接

应用Applications:
- Tractors
- Mid-sized agricultural equipment
- Agricultural attachments requiring breakaway
- 拖拉机
- 中等大小农机设备
- 需要拉断操作的农机属具

Technical Specifications

Rigid Mount, Connect Under Pressure, 1/2” Pioneer Agricultural Quick Couplings, ISO 5675, 3000 psi, - 8450 Series Couplers 型号
